- Arc welding source in D.C. welding
- Electronic regulation of welding current
- A.C. generator, single phase and three phase
- Aux power also available while welding
- Ground fault interrupter
- Output Sockets : 1x400V 16A 3P+N+T CEE - 1x230V 16A 2P+T CEE - 1x48V 32A 2P CEE
- LOMBARDINI diesel engine
- Electric Starter
- Protective frame
- Manual trolley CTM (on request)
- Welding remote control (on request)
- Meets EC directives
|
|
|
| |
 |
|
- Remote control : TC2 (cable 20m - TC2/50 (cable 50m)
|
| |
|
- Welding kit (mask, gloves etc.)
|
| |
|
|
| |
- Welding cables : K190 (10+8m, 35mm square) , K200 (20+15m, 35mm square)
|
|
| |
|
 |
|
|
| |
|
D. C. WELDING (Constant Current) |
|
Current range, continuous |
20A / 250A |
Service |
250A 35% - 200A 60% |
Duty Cycle |
70 V |
|
D. C. GENERATION - 50Hz |
Three phase asyncronous, alternator, self excited, self regulated, brushless |
|
Three - phase generation |
6.5 kVA / 400 V / 9.4 A |
Single - Phase generation |
4.5 kVA / 230 V / 19.5 A |
Single - Phase generation |
4.5 kVA / 110 V /40.9A |
Booster - engine starting service |
200 A/12 V c.c. - 24V c.c |
Insulation Class |
H |
|
ENGINE |
Diesel, 4-stroke, Direct injection,air cooled |
|
Model |
Lombardini 12LD 477/2 |
* Output |
14.9 kW (20.3 HP) |
Speed |
3000 rpm |
Cyclinders / Displacements |
2/ 954cm cube |
Fuel Consumption |
1.7 l/h |
* Maximum output ( not overloadable) according to ISO 3046/1 |
|
|
Tank Capacity |
9 I |
Running Time (Welding 60%) |
5.3 h |
IP Protection degree |
IP 23 |
* Dimensions L x I x h (mm) |
1050 x 530 x 630 |
* Dry Weight |
200 kg |
** Acoustic power LwA (Pressure LpA) |
103 dB(A) (78 dB (A) @7m) |
* Values shown do not include trolleys. **For fixed installation only |
| |
|
| Values shown are nominal values. For further information please contact the sales department . |
|
| |
| |
|
| |
