ENGINE DRIVEN WELDER WG 230 SX/EL


  • Arc welding source in D.C. welding
  • Welds any type of electrode, including cellulosic
  • High frequency welding current and voltage control
  • A.C. generator, single phase and three phase
  • Aux power also available while welding
  • Ground fault interrupter
  • Yanmer, diesel engine
  • Electric Starter
  • Engine protection EV
  • Engine Power Optimizer
  • super silenced
  • Trolley CTM2 (on request)
  • Remote control (optional)
  • Yanmer, diesel engine
  • Meets EC directives for noise and security



  • 400V / 230V/ 110V/ 48V plugs
  • Welding cables K200 (20+15m, 35mm square)

  • Remote control : TC2 with cable 20m
  • kit exhaust extension

  • Welding kit (mask, gloves etc.)
  • Earthing Kit

  • Remote control : TC2/50 with cable 50m
  • Manual trolley CTM2

  • Welding cables K190 (10+8m, 35mm square)
  • Road trolley CTM2

  • Auxiliary output : 400Y - 230I -48I : 1x400V 16A 3P+N+T CEE - 1x230 16A 2P+T Cee (SCHUKO) - 1x48V 32A 2P CEE

  • Auxiliary output : 230I -110I-CTE : 1x230 16A 2P+T CEE- 1x110 32A 2P+T CEE - 1x110V 16A 2P+T CEE

Technical data
WGD 230 SX/EL
D. C. WELDING (Constant Current)
Current range, continuous
20 - 210A
Service
210 A -60% , 180 A - 100%
Duty Cycle
65 V
D. C. GENERATION - 50Hz
50 Hz, asynchronous, three phase, self excited, self regulated, brushless
Three - phase generation
6 kVA / 400 V / 8.7 A
Single - Phase generation
5 kVA / 230 V / 21.7 A
Single - Phase generation
2.5 kVA / 110 V /22.7 A
Single - Phase generation
2 kVA/ 48V/ 41.6 A
Insulation Class
H
ENGINE
Diesel, 4-stroke, air cooled , direct injection
Model
Yanmar L 100 N
* Output
6.5 kW (8.8 HP)
Speed
3000 giri/min
Displacements / Cyclinders
1/435 cm cube
Fuel Consumption (Welding 60%)
1 I/h
* Maximum output ( not overloadable) according to ISO 3046/1
GENERAL SPECIFICATIONS
Tank Capacity
23 I
Running Time (Welding 60%)
20 h
IP Protection degree
IP 23
* Dimensions L x I x h (mm)
1020 x 645x 930
* Dry Weight
230 kg
**Measured Acoustic power
91 dB (A)(66 dB(A) @ 7 m)
**Guranteed Acoustic power
92 dB (A)(67 dB(A)@ 7 m)
*Values shown do not include trolleys.** Acoustic power according to 2000/14/CE

Values shown are nominal values. For further information please contact the sales department .
